Adding Apache Spark to Astronomer

At Astronomer, we're creating a platform to make it radically easier for both novice and expert data engineers to create and deploy data pipelines. Sometimes a step in a data pipeline is exceptionally long-running.

Would those steps benefit from Apache Spark to speed up the processing? Should we delegate all steps to Spark, or only the long-running ones? How would Spark affect the cost to execute the work?

Our hypothesis was that it would be a tradeoff: we'd get speed, but the job would cost more to execute. However, this speed would be worth it for customers who want their data in real time.

The Test

To test Spark, we focused in on a pipeline that scans user clickstream events for a high-volume web application, and writes daily summary data to Redshift. This data is then used to visualize how the usage is changing over time, at a very granular level.

Our approach was to:

  1. Build a script to do the work using our standard functionality.
  2. Build an Aries/Spark integration, and write a script to use that infrastructure.


Note: Aries is an open-source Javascript framework that powers certain aspects of the platform.

The Code

This task requires very little code, thanks to the power of Node and Aries. In fact, 90% of our time on this adventure went to setting up Spark on AWS.

First, we wrote the pipeline code... it's just two steps:

  • An activity that sets Spark up to use S3 as a backend, pointing to yesterday's data bucket.
  • Write the results of step 1 to Redshift, to a table called daily-clickstream-stats.

Pipeline Configuration

{ "interval" : "86400", "activityList" : { "name" : "aries-activity-acme-daily-analysis" }, { "name" : "aries-activity-redshift-sink", "config" : { "schema" : "astronomer_prod", "table" : "daily-clickstream-stats", "connection" : "acme-redshift" } } }

Spark-Enhanced Activity

import { SparkActivity } from 'aries-data'; import AWS from 'aws-sdk'; import moment from 'moment';

export default class AcmeDailyAnalysis extends SparkActivity { static props = { name: require('../package.json').name, version: require('../package.json').version, };

@singleS3StreamOutput()
async onTask(activityTask, config) {
    // Create a dataframe from s3 files.
    const dataframe = this.sqlContext.read().jsonSync(this.s3Path());

    // Spark query
    const ctx = df.select("context.userAgent")
        .groupBy('userAgent')
        .count()
        .sort('count')

    // Run the job and return the results.
    return ctx.collectSync();

 }

// Return a s3 path for yesterdays data.
s3Path() {
const yesterday = moment.utc().subtract(1, 'day').format('YYYY/MM/DD');
    return `s3n://acme-clickstream/data/${yesterday}/*`;
}

};

With just 30 lines of code, we get the power to process data from any S3 bucket and push summary data to any destination supported by Aries.

Results

Setup** Task Runtime **Cost Standard Astronomer infrastructure
(1 m3.medium EC2 instance) 50 minutes $0.067/hr x .83 hr =
$0.06 3-slave m3.medium Spark cluster 14 minutes $0.067/hr * 3 slaves * .23 hr =
$0.05 4-slave m4.xlarge Spark cluster 8 minutes $0.239/hr * 4 slaves * .13 hr =

$0.12

We discovered that tuning the infrastructure to the task is important.

  • With a modest Spark setup the task ran 4 times faster, and cost less.
  • With a bigger Spark cluster, the task ran 6 times faster, but doubled our original cost.

Next Steps

We're excited to have a proof-of-concept Spark integration now with Astronomer, but we'll have to think about how to utilize it effectively. Spark is not a magic bullet.

If any readers have advice on how to optimize Spark clusters for target workload, we'd love tips.
