Github API to Redshift with Apache Airflow
In this guide, we’ll explore how you can use Apache Airflow to move your data from Github to Redshift. Note that this is an effective and flexible alternative to point-and-click ETL tools like Segment, Alooma, Xplenty, Stitch, and ETLeap.
Before we get started, be sure you have the following on hand:
- A Github account
- An S3 bucket with a valid
- A Redshift instance with a valid host IP and login information
- An instance of Apache Airflow. You can either set this up yourself if you have devops resources or sign up and get going immediately with Astronomer’s managed Airflow service. Note that this guide will use commands using the Astronomer CLI to push dags into production and will assume you’ve spun up an Airflow instance via Astronomer, but the core code should work the same regardless of how you’re hosting Airflow
- Docker running on your machine
This DAG copies the following objects:
1. Add Connections in Airflow UI
Begin by creating all of the necessary connections in your Airflow UI. To do this, log into your Airflow dashboard and navigate to Admin-->Connections. In order to build this pipeline, you’ll need to create a connection to your Github account, your S3 bucket, and your Redshift instance. For more info on how to fill out the fields within your connections, check out our documentation here.
2. Clone the plugin
If you haven't done so already, navigate into your project directory and create a
plugins folder by running
mkdir plugins in your terminal. Navigate into this folder by running
cd plugins and clone the Github Plugin using the following command:
git clone https://github.com/airflow-plugins/github_plugin.git
This will allow you to use the Github hook to establish a connection to Github and extract data into a file. You will also be able to use the appropriate operators to transfer the Github data to S3 and then from S3 to Redshift.
3. Copy the DAG file
Navigate back into your project directory and create a
dags folder by running
mkdir dags. Copy the Github to Redshift DAG file into this folder.
Open up the github_to_redshift.py file that you just copied in a text editor of your choice and input the following credentials into lines 29-35:
S3_CONN_ID = '' S3_BUCKET = '' REDSHIFT_CONN_ID = '' REDSHIFT_SCHEMA = '' ORIGIN_SCHEMA = '' SCHEMA_LOCATION = '' LOAD_TYPE = ''
5. Test + Deploy
Once you have those credentials plugged into your DAG, test and deploy it!
If you don't have Airflow already set up in your production environment, head over to our getting started guide to get spun up with your own managed instance!
